Sundown Audio U-10 D2 10" 1500W RMS Dual 2-Ohm U-Series Subwoofer

Features

• Features: Black Aluminum 3 voice coil former for superior heat dissipation, High Temperature Round-Wire CCAW voice coil with high-temp black adhesive, Double stitched surround, Heavy duty cast basket, Spring loaded terminals accept up to 8 gauge, Stitched-on double-XL tinsel leads, Rear vented pole piece, Rear drilled gap-venting, Innovative high-velocity cast aluminum vented frame spacer ring, Magnet ID shorting ring, Top-Plate Cooling Channels, Cast Aluminum surround bolt-on rings, Optimized
• Specifications: 1500 Watts RMS | Linear X-Max by 70% | Magnet Diameter: 8.66 in. | DC Resistance (Re): 3.8 | Resonance Frequency (Fs): 48.5 Hz | Equivalent Volume (Vas): 8.3 L | Electrical Q Factor (Qes): 0.35 | Mechanical Q Factor (Qms): 3.20 | Total Q Factor (Qts): 0.32 | Force Factor (BL): 26.8 NA | Moving Mass (incl. Air Load) (Mms): 216.3 g | Suspension Compliance (Cms): 0.05 mm/N | Sensitivity: 86.2 dB 1w / 1m
• Box Recommendations: Sealed Enclosure Suggestion: 0.5 cu. ft. | Ported Enclosure Suggestion: 1.0 cu. ft. | Displacement: 0.21 cu. ft. | Depth: 7.007 in |Outside Diameter: 10.94 in | Cutout: 9.17 in | Recommended Tuning: 32 Hz | Recommended Port Area: 16 sq. in.

Description

The long awaited and highly anticipated Sundown Audio "U Series" subs are finally here. Jacob Fuller and the team spent over a year to design, engineer, and tool proprietary elements to ensure the U-Series stands up to the incredibly high expectations set by Sundown and their lineup. The “U Series” utilizes the same 1500 watt RMS Voice Coil as the entire X-V2 (10-18") series with a similar rear-vented motor design. The “U Series” is the most direct replacement in the Sundown line for the world famous Z-v.3 series that was available from 2011 through 2016. The “U” varies from its similarly power- rated sibling, the “X” series, in that it does not use the “Sundown new platform” frame, spider, and surround technology. The “U” series is equipped with an extremely capable “traditional” suspension design – which results in a “punchier” sound when compared to the “new platform” woofers. It also lends itself better to high-frequency SPL competition classes for the same reason. The list of "custom tooled" parts designed specifically for this sub is seemingly never-ending; including custom cone body, custom surround (larger and thicker than the Z-v.3 series), custom cast aluminum vent spacers, and a completely new cast aluminum surround bolt-on ring. Along with every other Sundown model, WoofersEtc is proud to offer a 2-year warranty against any defect in parts and labor.

Brand: Sundown Audio

Speaker Maximum Output Power: 1500 Watts

Frequency Response: 48.5 Hz

Connectivity Technology: Bluetooth

Audio Output Mode: Surround

Mounting Type: ‎Adhesive

Material: ‎Aluminum

Model Name: ‎Sundown Audio U-10 D2

Speaker Type: ‎Woofer

Recommended Uses For Product: ‎Volume

Compatible Devices: ‎Laptop, Desktop, Home Theater

Subwoofer Diameter: ‎10 Inches

Controller Type: ‎ring

Surround Sound Channel Configuration: ‎2.0

Product Dimensions: ‎10.94"D x 7.01"W x 10.94"H

Impedance: ‎3.8 Ohm

Is Waterproof: ‎FALSE

Warranty Type: ‎Limited

Number of Items: ‎1

Control Method: ‎Touch

Speaker Size: ‎10 Inches

Power Source: ‎Corded Electric

Woofer Diameter: ‎10 Inches

Vehicle Service Type: ‎Car

Customer Package Type: ‎Flat Free Package (FFP)

Audio Driver Type: ‎Dynamic Driver

Audio Driver Size: ‎10.94 Inches

Subwoofer Connectivity Technology: ‎Wired

Connectivity Protocol: ‎XLR

Includes MP3 player?: ‎No

Number of Power Levels: ‎1

UPC: ‎796516055107

Manufacturer: ‎Sundown Audio

Item Weight: ‎44.6 pounds

Item model number: ‎U-10

Is Discontinued By Manufacturer: ‎No

Manufacturer Part Number: ‎U-10 D2

Wattage: ‎1500 watts

Date First Available: March 20, 2018
