At a glance
- Condition
- New
- Model
- U-10
- Dimensions
- 10.94"D x 7.01"W x 10.94"H
- Color
- black
- Frequency Response
- 48.5 hertz
- Audio Output Mode
- Surround
- Mounting Type
- Adhesive
- Works with
- Laptop, Desktop, Home Theater
Features 3
- FEATURES - 3" black aluminum voice coil for superior heat dissipation, high temperature round wire CCAW voice coil with high temperature black adhesive, double wraparound stitching, heavy duty casting basket, spring loaded terminals accept up to 8 gauge, double xl tinsel wires, rear vented post piece, rear perforated vented vented vent, high speed die cast aluminum vented frame innovative spacer ring, magnetic identification short circuit ring. TopPlaca Plate RefrigerRefrigeranales, cast aluminum wrap-around screw rings, optimized
- Specifications: 1500 Watts RMS | Linear X-Max at 70% | Magnet Diameter: 8.6 in. | DC Resistance (Re): 3.8 | Resonance Frequency (Fs): 48.5 Hz | Equivalent Volume (Vas): 8.3 L | Electrical Q Factor (Qes): 0.35 | Mechanical Q Factor (Qms): 3.20 | Total Q Factor (Qts): 0.32 | Force Factor (BL): 26.8 Movs MovMovMovMovMovMov. MovMovS (incl. Air Load) (Mms): 216g | Suspension Compliance (Cms): 0.05 mm/N | Sensitivity: 86.2 dB 1w / 1 m
- Box Recommendations: Sealed Box Suggestion: 0.5 cu. feet | Cover box suggestion: 1.0 cu. feet | Displacement: 0.21 cu. Ft. | Depth: 7" | Outside Diameter: 10.9" | Cutout: 9.25" | Recommended Setting: 32Hz | Recommended Port Area: 16 sq. in.
Description
The long awaited and highly anticipated Sundown Audio "U Series" subs are finally here. Jacob Fuller and the team spent over a year to design, engineer, and tool proprietary elements to ensure the U-Series stands up to the incredibly high expectations set by Sundown and their lineup. The “U Series” utilizes the same 1500 watt RMS Voice Coil as the entire X-V2 (10-18") series with a similar rear-vented motor design. The “U Series” is the most direct replacement in the Sundown line for the world famous Z-v.3 series that was available from 2011 through 2016. The “U” varies from its similarly power- rated sibling, the “X” series, in that it does not use the “Sundown new platform” frame, spider, and surround technology. The “U” series is equipped with an extremely capable “traditional” suspension design – which results in a “punchier” sound when compared to the “new platform” woofers. It also lends itself better to high-frequency SPL competition classes for the same reason. The list of "custom tooled" parts designed specifically for this sub is seemingly never-ending; including custom cone body, custom surround (larger and thicker than the Z-v.3 series), custom cast aluminum vent spacers, and a completely new cast aluminum surround bolt-on ring. Along with every other Sundown model, WoofersEtc is proud to offer a 2-year warranty against any defect in parts and labor.
Specs 36
| Brand | Sundown Audio |
|---|---|
| Speaker Maximum Output Power | 1500 watts |
| Frequency Response | 48.5 hertz |
| Connectivity Technology | Bluetooth |
| Audio Output Mode | Surround |
| Mounting Type | Adhesive |
| Enclosure Material | Aluminum |
| Speaker Type | Woofer |
| Additional Features | Durable |
| Antenna Location | Volume |
| Subwoofer Diameter | 10 inches |
| Color | black |
| Is Waterproof | FALSE |
| Warranty Type | Limited |
| Control Method | Touch |
| Speaker Size | 10 inches |
| Woofer Diameter | 10 inches |
| Controller Type | ring |
| Number of Audio Channels | 2 |
| Impedance | 3.8 ohm |
| Compatible with Vehicle Type | Car |
| Power Source | Corded Electric |
| Model Number | U-10 |
| Model Name | Sundown Audio U-10 D2 |
| Built-In Media | 1 x Subwoofer |
| Number of Items | 1 |
| Customer Package Type | Flat Free Package (FFP) |
| UPC | 796516055107 |
| Manufacturer | Sundown Audio |
| Number of Power Levels | 1 |
| Item Dimensions D x W x H | 10.94"D x 7.01"W x 10.94"H |
| Wireless Technology | No Wireless Communication Technology |
| Subwoofer Connectivity Technology | Wired |
| Connectivity Protocol | XLR |
| Audio Driver Type | Dynamic Driver |
| Audio Driver Size | 10.94 inches |
