Sundown Audio SA-10 V.3 D4 10" Dual 4 Ohm Subwoofer - 1500W RMS / 3000W Peak - 22mm Xmax High-Excursion Car Sub - 8.11" Mount Depth - Low Distortion for Sealed/Ported Enclosures

Features

• EXTREME POWER HANDLING: The Sundown Audio SA-10 V.3 D4 handles a massive 1500 Watts RMS (3000 Watts Peak), delivering earth-shattering bass for the most demanding car audio systems. This robust power capacity ensures loud, consistent, and deep low-frequency reproduction, pushing the limits of your audio experience without compromise.
• ULTRA-HIGH EXCURSION & LOW DISTORTION: Featuring an impressive 22mm Xmax (one-way linear excursion), this 10" subwoofer moves significant air, producing incredibly deep and impactful bass notes with exceptional clarity. Its low distortion motor construction and new surround with linear geometry ensure pristine, accurate sound even at extreme volumes.
• VERSATILE DUAL VOICE COIL OPTIONS: Equipped with Dual 4 Ohm (or Dual 2 Ohm available) voice coils, the SA-10 V.3 offers unparalleled wiring flexibility. Easily configure your system for a 2 Ohm or 8 Ohm final load (for D4 version), ensuring optimal power transfer and compatibility with a wide range of amplifiers for peak performance.
• OPTIMIZED FOR ANY ENCLOSURE: Designed for supreme versatility, this subwoofer performs exceptionally in both sealed and ported enclosures. Recommended volumes are 0.5 cu ft for sealed and 1.0 cu ft for ported (tuned to 35Hz with 15 sq in port area). Its precision engineering ensures tight, accurate bass regardless of your chosen box type.
• ROBUST BUILD & PRECISE DIMENSIONS: With an 8.11" mounting depth and 11" outer diameter , the SA-10 V.3 D4 boasts a patented high-strength cast aluminum frame. Integrated 16 chamfered gap vents and high-temperature voice coil wire ensure superior thermal performance and durability for long-lasting, high-fidelity audio

Description

Sundown Audio SA-10 V.3 D4 10" Dual 4 Ohm Subwoofer: Unleash Unprecedented Bass Power & PrecisionExperience the pinnacle of low-frequency performance with the Sundown Audio SA-10 V.3 D4 10" Dual 4 Ohm Subwoofer. Engineered for uncompromising bass enthusiasts, this high-excursion driver delivers immense power handling, exceptional clarity, and versatile installation options. Whether you crave chest-thumping lows for competition or articulate, distortion-free bass for daily listening, the SA-10 V.3 D4 is meticulously designed to exceed expectations in any car audio system.𝐄𝐗𝐓𝐑𝐄𝐌𝐄 𝐏𝐎𝐖𝐄𝐑 𝐇𝐀𝐍𝐃𝐋𝐈𝐍𝐆 & 𝐃𝐘𝐍𝐀𝐌𝐈𝐂 𝐎𝐔𝐓𝐏𝐔𝐓: The Sundown Audio SA-10 V.3 D4 commands attention with its staggering power capabilities, effortlessly handling 1500 Watts RMS (3000 Watts Peak). This incredible power capacity ensures that the subwoofer can reproduce the deepest bass notes with authority and unwavering control, allowing your system to deliver a truly immersive and impactful low-frequency experience. Every beat is rendered with astonishing force and clarity, providing an exhilarating audio journey. Its BL of 22.267 NA and Mms of 304.447 Grams highlight its powerful motor structure.𝐔𝐋𝐓𝐑𝐀-𝐇𝐈𝐆𝐇 𝐄𝐗𝐂𝐔𝐑𝐒𝐈𝐎𝐍 𝐃𝐄𝐒𝐈𝐆𝐍 𝐅𝐎𝐑 𝐃𝐄𝐄𝐏 𝐁𝐀𝐒𝐒: Central to the SA-10 V.3 D4's exceptional performance is its 22mm Xmax (one-way linear excursion). This extensive cone movement capability allows the subwoofer to displace a massive amount of air, translating directly into incredibly deep, impactful, and dynamic bass notes. You won't just hear the bass; you'll feel it resonating through your entire vehicle. This high-excursion design is crucial for delivering powerful low-end extension with precision and minimal distortion, even at extreme volumes.𝐕𝐄𝐑𝐒𝐀𝐓𝐈𝐋𝐄 𝐃𝐔𝐀𝐋 4 𝐎𝐇𝐌 𝐕𝐎𝐈𝐂𝐄 𝐂𝐎𝐈𝐋 𝐂𝐎𝐍𝐅𝐈𝐆𝐔𝐑𝐀𝐓𝐈𝐎𝐍𝐒: The SA-10 V.3 D4 offers unparalleled flexibility with its Dual 4 Ohm voice coils. This design empowers you to optimize the impedance load to perfectly match your amplifier's capabilities, ensuring maximum power transfer and efficiency. You can easily wire the subwoofer for a 1 Ohm (parallel) or 4 Ohm (series) final impedance, making it adaptable to a wide range of custom setups. The RE of 3.4 Ohms indicates its efficient electrical characteristics, giving you "Total System Control" over your bass.𝐎𝐏𝐓𝐈𝐌𝐈𝐙𝐄𝐃 𝐅𝐎𝐑 𝐀𝐍𝐘 𝐄𝐍𝐂𝐋𝐎𝐒𝐔𝐑𝐄 𝐓𝐘𝐏𝐄 & 𝐋𝐎𝐖 𝐃𝐈𝐒𝐓𝐎𝐑𝐓𝐈𝐎𝐍: Designed for supreme acoustic versatility, this 10" subwoofer performs exceptionally well in both sealed and ported enclosures. For tight, articulate bass, a sealed enclosure of just 0.5 cu ft is recommended. If you crave maximum SPL and deeper extension, a ported enclosure of 1.0 cu ft tuned to 35Hz with a 15 sq in port area will unleash its full potential. Its low distortion motor construction and new surround with linear geometry ensure a clean, accurate acoustic response. The Qts of 0.413 highlights its balanced performance characteristics.𝐑𝐎𝐁𝐔𝐒𝐓 𝐂𝐎𝐍𝐒𝐓𝐑𝐔𝐂𝐓𝐈𝐎𝐍 & 𝐀𝐃𝐕𝐀𝐍𝐂𝐄𝐃 𝐓𝐇𝐄𝐑𝐌𝐀𝐋 𝐌𝐀𝐍𝐀𝐆𝐄𝐌𝐄𝐍𝐓: Built to endure the most demanding audio environments, the SA-10 V.3 D4 features a robust construction. It includes a patented high-strength cast aluminum frame for exceptional rigidity and durability. Advanced thermal management is provided by a vented magnetic gap with 16 chamfered vents that promote high-velocity air circulation over the high-temperature voice coil wire, ensuring consistent performance and preventing thermal compression. Stitched-on “XL” tinsel lead wires and spring-loaded terminals ensure reliable connections. With an 8.11" mounting depth, 11" outside diameter, and 9.5" cutout diameter, it's a powerful and precise choice for custom car audio installations.

Brand: Sundown Audio

Speaker Maximum Output Power: 1250 Watts

Connectivity Technology: Subwoofer

Mounting Type: Wall Mount

Material: Aluminum

Mounting Type: Wall Mount

Enclosure Material: Aluminum

Speaker Type: Subwoofer

Additional Features: Bass Boost

Antenna Location: Subwoofer

Is Waterproof: False

Speaker Size: 10 Inches

Woofer Diameter: 10 Inches

Specific Uses For Product: Subwoofer

Speaker Maximum Output Power: 1250 Watts

Unit Count: 1.0 Count

Item Dimensions D x W x H: 6.5"D x 10.5"W x 6.5"H

Item Weight: 37 Pounds

Audio Driver Type: Dynamic Driver

Audio Driver Size: 10 Inches

Brand: Sundown Audio

Model Number: 8

Model Name: SW-SAV310D4

Number of Items: 1

Customer Package Type: Manufacturer

UPC: 810111133838

Manufacturer: Sundown Audio

Connectivity Technology: Subwoofer

Wireless Technology: No Wireless Communication Technology

Compatible Devices: Car Audio Systems
