Outboard Motor, 2 Stroke 6 hp 102cc Heavy Duty Boat Engine Fishing Boat Motor w/CDI System Water Cooling System (2 Stroke 6 hp)

Features

• 2 STROKE 6 HP OUTBOARD MOTOR BOAT ENGINE2 stroke 6HP power, Water cooling technology to improve the reliability of the whole machine. Superior engine water cooling system for improved engine performance Made of special high-strength aluminum alloy material with high hardness, strong durability, good rust and corrosion resistance.
• SIZE & PREFORMANCEOverall length 1040mm(40.9 in); Overall width 872mm(34.3 in); Overall height 332mm(13.1 in); Transom height 44CM(17.3 in); Short shaft: 40cm(15.7 in); Full throttle operating range 5000-6000r/min; Maximum output 4.4KW/6HP; Idling speed ( in neutral) 1000100 r/min.Engine oil mixing ratio Fuel 50: Engine oil 1;Gear oil quantity 195ml(6.6 fl.oz.);Tightening torque for engine;Spark plug 25.0Nm(18.4 ft-lb) (2.55 kgf-m);Engine oil drain bolt 18.0Nm(13.3 ft-lb) (1.84 kgf-m).
• WIDE APPLICATIONPerfect match inflatable boats, fishing boats, sailboats, and small yachts.(The outboard motors are all installed on the stern straight plate and cannot be installed in other places)
• WARM TIPSPlease add gear oil to the gears before use the motor and replace gear oil after the run-in period(10hours). (if you do not know how to handle this, please contact with us ); We can only provide CE certification, there is no other certification can be provided,thanks for your understanding.
• ABOUT USWe have our own overseas warehouse and a professional Customer Service Team to reply you within 24 hours We promise you that we will do our ultmost to solve it for you firstly.

Description

DescriptionNotice: Please add gear oil to the gears before use the motor and replace gear oil after the run-in period（10hours）. (if you do not know how to handle this, please contact with us Specification Short shaft: 40cm/15.7'' Dimension Overall length 1040mm(40.9 in)Overall width 872mm(34.3 in)Overall height 332mm(13.1 in)Transom height 44CM(17.3 in)PerformanceFull throttle operating range 5000-6000r/minMaximum output 4.4KW/6HPIdling speed ( in neutral) 1000±100 r/minEngine Gear positions Forward-neutral-reverseGear ratio 2.15(28/13)Trim and tilt system: Manual tiltDrive unit Recommended fuel Regular unleaded gasolineIntegral fuel tank capacity 2.5LRecommended engine oil 2-stroke outboard motor oilEngine oil type Genuine or recommended 2str engine oilLubrication System Engine oil mixed gasolineEngine oil mixing ratio Fuel 50: Engine oil 1Gear oil quantity 195ml(6.6 fl.oz.)Tightening torque for engine Spark plug 25.0Nm(18.4 ft-lb) (2.55 kgf-m)Engine oil drain bolt 18.0Nm(13.3 ft-lb) (1.84 kgf-m)Otherssingle-cylinderThe exhaust port is underwaterWith reverse gear Gasoline engine. Use oil

Brand: TBVECHI

Item Weight: 45.3 Pounds

Color: Black

Material: Aluminum

Engine Displacement: 102 Cubic Centimeters

Brand: ‎TBVECHI

Item Weight: ‎45.3 Pounds

Color: ‎Black

Material: ‎Aluminum

Engine Displacement: ‎102 Cubic Centimeters

Engine Type: ‎2 Stroke

Operation Mode: ‎Manual

Recommended Uses For Product: ‎For Fishing Boats, For Inflatable Boats

Mounting Type: ‎Engine Mount, Transom Mount

Fuel Type: ‎Gasoline

Maximum Horsepower: ‎6 Horsepower

Fuel Capacity: ‎2.5 Liters

Product Dimensions: ‎34.3"D x 13.1"W x 40.9"H

Manufacturer: ‎Ethedeal

UPC: ‎738634818202

Model: ‎Outboard motor

Item Weight: ‎45.3 pounds

Item model number: ‎2 Stroke 6ph

Exterior: ‎Painted

Manufacturer Part Number: ‎OT-073-ED

Safety Rating: ‎SPT3.5MS03222

Date First Available: September 21, 2020
