Non-Programmable Thermostats for Home Conventional Single-Stage Systems, up to 1 Heat/ 1 Cool (with White Backlight)

Features

• NoticeBuyers should thoroughly examine the installation and wiring instructions depicted in the images before buying. It is recommended to exercise caution if you lack experience in installation to avoid potential problems like product malfunction or incompatibility due to incorrect purchases. Note that the base can only be attached with a maximum of 2 to 5 wires, and connections with 6 to 8 wires are not suitable.
• Thermostat Applications 1H/1Cfor with Conventional Single-Stage Heating & Air Conditioning, up to 1 Heat and 1 Cool. and Gas/Oil/Electric Furnace (1 Heat only), Boiler Radiant (1 Heat only), Furnace Forced-Air (1 Heat Only), Gas Fireplace (24 Volts), Cooling Only, Only 1H/1C Heat Pump (without aux) Systems.
• Incompatible SystemsDoes not work multistage systems (1H/2C, 2H/2C), HVAC heat pump systems (2H/1C, 4H/2C), PTACs, 3-wire hydronic (hot water), dual fuel/hybrid heating. Does not work line voltage systems (120-240V electric baseboards heat); mini split heat pump air conditioner, RV air conditioners mach and roughneck series.
• Heagstat H701 Non-programmable thermostat for house conventional single-stage systems up to 1 heat/1 cool, to control the temperature in a room.
• Accurate temperature control of +/-1-Degree F for consistent comfort, Room temperature display range: 41F to 95F, Temperature control range: 44F to 90F.
• Separate Heating and Cooling Swing (Cycle Rate). Which will Either Prolong or Shorten the Temperature Open Time. Make Comfortable Temperatures to Teduce Energy Usage, Savings on Annual Heating and Cooling Costs.
• Support room temperature error display calibration adjustment and 5 minute compressor delay protection (Selectable on or off), with low battery indicator available change reminder (Tip: Please replace the accessories in advance).
• Support Dual Powered 24VAC Power or 2 AAA Batteries. No Common Wire (c-wire) Rrequired on Most Single-Stage Systems.
• Display with White Backlight, Easy-to See and Read. Large, Clear Backlit Digital Display, Very Suitable for Middle-Aged and Elderly People.
• After-sales Service: If you have any problem, please feel free to contact us, we will repley you in 24 hours. the products come with 30 days free return, 2-year Worry-Free Warranty.

Brand: Heagstat

Model Name: Simple 1H/1C Thermostat

Product Dimensions: 0.98"D x 4.72"W x 3.86"H

Controller Type: conventional single stage systems

Special Feature: Separate Heating and Cooling Swing (Cycle Rate), Compressor Delay Protection

Brand: Heagstat

Model Name: Simple 1H/1C Thermostat

Product Dimensions: 0.98"D x 4.72"W x 3.86"H

Controller Type: conventional single stage systems

Special Feature: Separate Heating and Cooling Swing (Cycle Rate), Compressor Delay Protection

Color: White Backlight

Specific Uses For Product: Single-Stage Heating (Gas/Oil/Electric Furnace), Ventilation, and Air Conditioning

Temperature Control Type: 1 Heating and 1 Cooling

Connectivity Technology: Wired

Included Components: thermostat, Two screws and anchors, Installation manual, Cable label

Power Source: Battery Powered

Item Weight: 0.4 Pounds

Voltage: 24 Volts (AC)

Material: Plastic

Shape: Rectangular

Display Type: LCD

Screen Size: 3 Inches

Control Type: Button Control

Control Method: Touch

Connectivity Protocol: BACnet MS/TP

Mounting Type: Wall Mount

Style: Digital

Backlight: Yes

Specification Met: energy

UPC: 602430103056

Manufacturer: Heagstat

Item Weight: 6.4 ounces

Item model number: H701

Is Discontinued By Manufacturer: No

Date First Available: April 26, 2018
