Features
Description
APlusLift HW-10KOH is one of most affortable overhead car lift (auto hoist) with 10000 LB capacity and strong double "S" columns.SpecificationsOverall Height: 143 3/16"Overall Width: 134 5/16"Lifting height without Truck Adapters: 75"Lifting height with Truck Adapters: 81"Minimum Height of Arm Top: 4.5"Drive Through Width (Carriage to Carriage): 100"Column to Column Width: 109"Column Cross Section: 11"L x 7"WDriving Mode: Dual hydraulic cylinders, chain driveMotor: 220V Single Phase 3HP (need a 30A breaker)Hydraulic Oil: 3-5 gallons AW32/AW46Time to full rise: 50 secCombo (Symmetrical and Asymmetrical) Arm AssemblyFront/Rear 3 Stage reach from 22 7/8" to 42 5/8"Rear 2 Stage reach from 33 5/8" to 52 7/8"Adjustable Screw Pads 4 pieces includedTruck adapters 4 pieces includedConcrete Requirement: 6" at 3500psi (4" for vehicles 9000LB and below)Anchor bolts, tool trays, and toe guards includedColumn Steel Thickness: 13/64"Carriage Steel Thickness: 15/64"Arm Steel Thickness: 15/64"Carriage Yoke Thickness: 5/16"Base Plate Steel Thickness: 5/8"FeaturesCE Certified Lift Structure and Hydraulic SystemCarriage Material Q355 (ASTM A572), Stronger Than Normal Q235 SteelRelief valve built in power pump to prevent overloadingAutomatic arm lock restraintsRelief valve built in power pump to prevent overloadingDoor guards protection rubberUp-limit switch to protect cylinders working stroke used in safe length scopeHeavy duty 3/8" diameter cable and 5" pulley that reduce high stress on synchronization process and increase cable lifeStiffened base plate 5/8" thickness
Load Capacity: 10000 Pounds
Maximum Lifting Height: 81 Inches
Brand: APlusLift
Color: Blue
Item Dimensions LxWxH: 134 x 20 x 143 inches
Load Capacity: 10000 Pounds
Maximum Lifting Height: 81 Inches
Brand: APlusLift
Color: Blue
Item Dimensions LxWxH: 134 x 20 x 143 inches
Style: 2-Post Car Lift
Manufacturer: Songa Enterprises
Model: HW-10KOH
Item Weight: 1450 pounds
Product Dimensions: 134 x 20 x 143 inches
Country of Origin: China
Item model number: HW-10KOH
Is Discontinued By Manufacturer: No
Exterior: Painted
Manufacturer Part Number: HW-10KOH
OEM Part Number: HW-10KOH
Mirror Adjustment: Hydraulic Power
Date First Available: March 4, 2018
