HOBBYWING Quicrun 10BL120 G2 & 3652SL G2 Combo (QR10BL120 G2 &3652SL 3250KV G2)

Features

• COMBO: QR10BL120 G2 ESC & 3652SL G2 Motor
• Intelligent freewheeling technology, greatly improved performance The innovative intelligent freewheeling technology enables higher driving efficiency and lower operating temperature of the ESC, and further improves the stability and reliability of the ESC.
• Powerful built-in BEC The ESC has a built-in BEC with a continuous current of 5A and supports a maximum output current of up to 10A. The output voltages are switchable between 6V, 7.4V. This ensures that the ESC is able to support the demanding high-torque servos in the market.
• Efficent cooling system The integrated radiator design, combined with the patented copper thermal conduction sink on the internal power board of the ESC, facilitates the rapid conduction of internal heat to the radiator, and the fan is added to dissipate heat. These results an efficient heat dissipation system to ensure that the ESC is always in a good heat dissipation state
• Capacitor Thermal Protection Capacitor thermal protection is designed and implemented into the ESC to effectively prevent capacitors from exploding and causing irreversible damages to the ESC due to overloading.
• High protection level, all-weather operation The IP-67 waterproof Rating guarantees excellent waterproof and dustproof protection. The whole power system is able to drive on a variety of surfaces including mud, sand, ice, snow and water without damaging the power unit.

Description

Excellent waterproof and dustproof performance, it is easy to deal with various climatic conditions and harsh environment. Smart freewheeling technology makes the esc have higher driving efficiency and lower operating temperature, and the stability and reliability of the esc are further improved. Built-in powerful switch mode BEC, continuous current up to 5A, instant up to 10A, and support 6V/7.4V adjustable, easy to drive various powerful and high-voltage steering servo. Multiple protection functions: battery low voltage protection, esc overheat protection, throttle signal loss protection, current protection, capacitor overheat protection. It has an independent programming port. When connecting the program card, it is not necessary to pull the throttle cable out of the receiver, which is more convenient to use.

Brand: HOBBYWING

Model Name: Quicrun 10BL120 G2 & 3652SL G2 Combo

Voltage: 6 volts, 7.4 volts

Product Dimensions: 1.56"W x 1.5"H

Material: ESC Plastic Housing | Aluminum Housing | PCB Motor Steel and Aluminum

Brand Name: HOBBYWING

Model Name: Quicrun 10BL120 G2 & 3652SL G2 Combo

Model: 38030207 | 38030208 | 38030209

Number of Items: 2

Manufacturer: Hobbywing Technology

UPC: 088718520157

Unit Count: 1 Count

Included Components: (1) Quicrun 10bl120 G2 ESC, (1) Quicrun 3652SL Motor, (2) Manual

Item Type Name: Brushless ESC and Motor Combo

Part Number: 38030207 | 38030208 | 38030209

Voltage: 6 volts, 7.4 volts

Item Dimensions W x H: 1.56"W x 1.5"H

Item Weight: 1.1 pounds

Material Type: ESC Plastic Housing | Aluminum Housing | PCB Motor Steel and Aluminum
