DRO 3 Axis Digital Readout Display +3pc Glass Linear Scale for CNC Mill Lathe Machine (450mm+500mm+1000mm)
Buy Now, Pay Later
- – Up to 36-month term if approved
- – No impact on credit to apply
- – Instant approval decision
- – Secure and straightforward checkout
Ready to go? Add this product to your cart and select a plan during checkout.
Payment plans are offered through our trusted finance partners Klarna, Affirm, Afterpay, Zip, Apple Pay, and Google Pay. No-credit-needed leasing options through Acima may also be available at checkout.
Learn more about financing & leasing here.
Selected Option
30-day refund/replacement
To qualify for a full refund, items must be returned in their original, unused condition. If an item is returned in a used, damaged, or materially different state, you may be granted a partial refund.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
Recently Viewed
Model: 450+500+1000
Features
- HIGH PERFORMANCE3Axis Digital Readout DRO Display 5um,Available Travel Length:450mm+500mm+1000mm(18"+20"+40").Note: The Total Length =Travel Length+140mm=590mm+640mm+1140mm. Travel Length Customizable
- HIGH PRECISEGlass precision Metrology Grating,Resolution 5um , Accuracy 5um/ 0.0002" (at 20 deg C);Pulse signal period 20um , Travelling Speed 100m/min,8 bit LED High-definition nixie tube.
- IDEAL PROFESSIONAL CHOICEThis is a complete kit. You just need to hook the readout system to your machine.It includes one 3 Axis Digital Readout, two scales, protective covers, brackets, etc, an english manual and all the accessories for installation.
- WIDE APPLICATIONApplicable for milling machine, drilling machine, grinding machine, lathes, profile projector, video measuring machine, position monitoring, coordinate measurement, X-Y-Z working table monitor, mechanical control as well as other area of linear scale and rotary encoder.
- All Products from the TOAUTO will be provided for 2-year warranty after-sales and lifetime technical support. You will receive 2 separate packages due to the different dimensions of scales and display if you only receive one of them, the other one is maybe on the way to you. Please just wait for a while.
Description
DRO is designed to match multi kinds of linear scale with resolution 0.05µm, 0.1µm, 0.2µm, 0.5µm, 1µm, 2µm, 5µm, 10µm, 20µm or 50µm. The DRO resolution must be set to completely match the linear scale precision. (This kit default is 5um/0.005mm/0.0002" resolution) Readout only allows TTL square wave signal input through 9 pins connector, which completely matches the linear scale encoder . Pin 1 to 4 connects +5V,0V,A,B , and the pin 5-9 are blank. Robust casing, high reliability and durability switch design. Full-closed design ensures its clean and dust resistance, safety increased. Having a good capacity of resisting disturbance,durable keyboard,easy to change Signal cable uses multilayer shielded wire steel and metal shell to provide extra protection . Deafult offer 3 meters (9.84feet long) cable connecting with linear scale. Full set of installation accessories (L type cover, backplate and screws ) included , each scale equipped with some extra screws to avoid unsccessful installation . Widely used for manual machine ,such as milling machine ( for Bridgeport Mill, Knee Mill,Rong Fu 31 mill / drill, Grizzly Mill,etc), drilling machine, grinding machine, lathe, EDM, linear cutting machines etc. Circumference holes processing Linear holes processing ARC processing Oblique processing Slope processing Chamber processing R function Tool diameter compensation function Digital filter radius diametr, mm/inch function etc. Supply Voltage : AC 80V~260V; 50~60Hz,US Plug Power consumption: 15VA Operating temperature: 0~45°C Storage temperature: -30~70°C Signal Input : TTL square wave Resolution : 5µm (0.005mm/0.0002") Overall Length : Travel Length + 140mm Linear Scale Interface: DB9(RS232)
Brand: TOAUTO
Material: Glass
Range: 590 millimeters
Measurement Accuracy: 5UM
Unit Count: 1 Count
Brand Name: TOAUTO
Unit Count: 1 Count
UPC: 778365356987
Set Name: Kit
Number of Items: 1
Manufacturer: TOAUTO
Number of Packs: 1
Item Weight: 5 kg
Model:
Part Number: DRO-NFT-004
Range: 590 millimeters
Measurement Accuracy: 5UM
Material Type: Glass
