ELEGOO UNO R3 Project Most Complete Starter Kit with Tutorial Compatible with Arduino IDE (63 Items)

Features

• More than 200 components, this is the most complete ELEGOO UNO R3 starter kit you will find. Great value starter kit with 63 kinds of products
• Has all the electronic components you need and a free PDF tutorial (more than 30 lessons) to show you how to use them. All code to use the modules is included
• All the modules come soldered so they are easy to wire up. Suitable for all kind of coding skill level
• Includes UNO R3 controller board and USB cable, compatible with Arduino UNO R3, and Arduino kit
• Kit comes packaged in compartmentalized case with a bonus box for small parts like LEDs, ICs, buttons, diodes, etc. It is easy to be well organized after use

Description

ELEGOO STEM kits provide all the necessary components, sensors, wires, and boards for you to get started with programming, learning electronics, and creating IoT projects. We strive our best to make STEM education easy to learn and accessible to the young generation. Visit the Store Visit the Store Visit the Store Chris, the founder of ELEGOO, found out that most enterprises in the STEM industry focused on the hardware of open-source electronics and did not have tools to create a complete product by combining electronic hardware and structural shells. We have excellent R&D team, constantly upgrading and improving products, and after-sales service team for quick support. 100% compatible with Arduino, ELEGOO's kits are best-practice for beginners who have no appropriate technical tools to learn about electronics. Want to learn how to work with electronics and programming but need a little help? You've come to the right place! ELEGOO UNO R3 Starter Kit provides an open-source electronics prototyping platform based on flexible, easy-to-use hardware and software, which evolves the user from beginner to professional level. Our starter kit is designed to get you started quickly and easily on your path of learning electronics. Originally this pack was designed to follow the introductory tutorials with 33 creative and fun projects on our website. But it's a great starter kit in general as it's designed for everyone even novices who has very little or no electronics and programming experience. The starter bundle contains everything you need (except tools) to take your first step on electronics journey! Electronics is not as complicated as you imagine especially with ELEGOO UNO R3 Starter Kit. For advanced users like professional lab engineers, electronic major students and experienced electronics hobbyists, they can use this kit to do various kinds of tests and experiments with so many sensors available at hand. What about novice users who don't have any electronics knowledge? Fear not amigo. Just follow our tutorial enclosed and step by step you will come to realize that learning electronics is more fun than you ever expected with this amazing sensor kit. It’s a good choice and kit for your kids, friends, family members whoever is obsessed with electronics, programming or robotics to take their first steps on electronics journey! Quantity and quality are both important here in ELELGOO UNO R3 starter kit. The most essential parts in this kit are UNO R3 controller board and expansion board, which is a clone with excellent product finish compatible with electronics projects. Besides, we offer other over 60 kinds of components and sensors from small parts like LED diodes, resistors and potentiometer to big parts like LCD1602, RFID module and 830 tie-points breadboard, which meet your demands for your different projects either it is simple or complex. Sturdy quality is definitely the most important thing to ELEGOO even with so many components provided we never compromised on the quality. Instead we keep improving our product quality in our own factory and we produce the products by ourselves under high standards and strict quality control. Pins and wires on some of the parts like LCD16502 and motors have been pre-soldered which is very convenient and saves your time. 74HC595 is a Serial to Parallel Converter which has eight outputs and three inputs that you use to feed data into it a bit at a time. This chip makes it a little slower to drive the LEDs (you can only change the LEDs about 500,000 times a second instead of 8,000,000 a second) but it's still really fast, way faster than humans can detect, so it's worth it! 74HC595 shift register is a type of chip that holds what can be thought of as eight memory locations, each of which can either be a 1 or a 0. To set each of these values on or off, we feed in the data using the 'Data' and 'Clock' pins of the chip. LCD1602 module is a display that has an LED backlight and can display two rows with up to 16 characters on each row. You can see the rectangles for each character on the display and the pixels that make up each character. The display is just white on blue and is intended for showing text. Lining up the display with the top of the breadboard helps to identify its pins without too much counting, especially if the breadboard has its rows numbered with row 1 as the top row of the board. Do not forget, the long yellow lead that links the slider of the pot to pin 3 of the display. The 'pot' is used to control the contrast of the display. In this project you will learn how to control a small DC motor using an UNO R3 and a L293D transistor, which is a very useful chip. It can actually control two motors independently. We are just using half the chip in this lesson, most of the pins on the right hand side of the chip are for controlling a second motor. L293D is quadruple high-current half-H drivers and designed to provide bidirectional drive currents of up to 1 A at voltages from 4.5 V to 36 V. The L293D is also designed to provide bidirectional drive currents of up to 600-mA at voltages from 4.5 V to 36 V and drive inductive loads such as relays, solenoids, dc and bipolar stepping motors, as well as other high-current/high-voltage loads in positive-supply applications.

Brand Name: ELEGOO

Age Range Description: Youth

Educational Objective: Coding Skills, Concentration, Creative Skills, Exploratory Skills, Logical Thinking, Problem Solving Skills, Programming Skills, STEM

Set Name: ELEGOO UNO R3 Most Complete Starter Kit

Manufacturer Maximum Age (MONTHS): 1200

UPC: 746591610364

Manufacturer Minimum Age (MONTHS): 120

Global Trade Identification Number: 64

Model Number: EL-KIT-001

Manufacturer Part Number: EL-KIT-001

Manufacturer: ELEGOO

Unit Count: 1.0 Count

Manufacturer Warranty Description: 1 Year Manufacturer

Included Components: 10pcs Resistor (1M); 20pcs Female-to-male DuPont Wire; 5pcs White LED; 5pcs Yellow LED; 5pcs Blue LED; 5pcs Green LED; 5pcs Red LED; 1pcs RGB LED; 5pcs 22pf Ceramic Capacitor; 5pcs 104 Ceramic Capacitor; 2pcs Photo resistor; 1pcs Thermistor; 5pcs Diode Rectifier (1N4007); 2pcs Electrolytic Capacitor (10UF 50V); 2pcs Electrolytic Capacitor (100UF 50V); 5pcs NPN Transistor (PN2222); 5pcs NPN Transistor (S8050); 1pcs Tilt Switch; 5pcs Button (small); 1pcs 1 digit 7-segment Display; 1pcs 4 digit 7-segment Display; 1pcs Sound Sensor Module; 1pcs LCD1602 Module ( with pin header); 1pcs IC L293D; 1pcs IC 74HC595; 1pcs Active Buzzer; 1pcs Passive Buzzer; 1pcs RTC Module; 1pcs DHT11 Temperature and Humidity Module; 2pcs Potentiometer; 1pcs Rotary Encoder Module, 1pcs Keypad Module; 1pcs 5V Relay; 1pcs IR Receiver Module; 1pcs UNO R3 Controller Board; 1pcs Breadboard; 1pcs Servo Motor (SG90); 1pcs Stepper Motor; 1pcs ULN2003 Stepper Motor Driver Board; 1pcs Prototype Expansion; 1pcs Power Supply Module WARNING Pls. do not use the voltage higher than 9V; 1pcs HC-SR501 PIR Motion Sensor; 1pcs Ultrasonic Sensor; 1pcs GY-521 Module; 1pcs 3V Servo Motor; 1pcs MAX7219 Module; 1pcs Remote; 1pcs 9V 1A Power Supply; 1pcs 65 Jumper Wire; 1pcs Water Lever Sensor; 1pcs USB Cable; 1pcs 9V Battery with DC; 1pcs RC522 RFID Module; 10pcs Resistor (10R); 10pcs Resistor (100R); 30pcs Resistor (220R); 10pcs Resistor (330R); 10pcs Resistor (1K); 10pcs Resistor (2K); 10pcs Resistor (5K1); 10pcs Resistor (10K); 10pcs Resistor (100K); 10pcs Resistor (1M)

Theme: Electronics, Engineering

Battery Description: Lithium

Is Assembly Required: Yes

Size: UNO R3 Project Most Complete Starter Kit

Item Dimensions: 13.7 x 8.4 x 1.85 inches

Item Weight: 2.2 Pounds
