CNCTOPBAOS DDCS Expert CNC Controller 4-Axis Linkage,G Code M Code Offline Standalone Motion Control System,Spindle/Servo/Stepper Motor for Engraving Milling Machine,Lathe,CNC Router,Plasma Cutters
Condition: New
Notify me when this product is back in stock
Buy Now, Pay Later
As low as
/ mo
Learn more
- – Up to 36-month term if approved
- – No impact on credit
- – Instant approval decision
- – Secure and straightforward checkout
Payment plans are offered through our trusted finance partners Klarna, Affirm, Afterpay, Apple Pay, and PayTomorrow. No-credit-needed leasing options through Acima may also be available at checkout.
Learn more about financing & leasing here.
Selected Option
Free shipping on this product
30-day returns
Learn more
This item is eligible for return within 30 days of receipt
To qualify for a full refund, items must be returned in their original, unused condition. If an item is returned in a used, damaged, or materially different state, you may be granted a partial refund.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
Availability:
Unavailable
Recently Viewed
Style: 4 Axis DDCS EXPERT Controller
Features
- Model: 4-Axis DDCS-EXPERT ; The DDCS-Expert is a small box that can fit in a window of a small control box or control cabinet. Four locking hooks fix this controller from the frame;The front panel is 268mmx172.5mmx5.2mm;Main body is 268mmx172.5mmx70 mm;To mount the unit in an equipment cabinet,cut the hole 258.4mmx109 mm
- Introduction: The DDCS Expert numerical control system adopts the ARM+FPGA design framework. ARM controls the human-computer interface and code analysis and the FPGA provides the underlying algorithms and creates the control pulse.The internal operating system is Linux base; Applications:The DDCS Expert can be used for many styles and types of CNC machines. Lathes, CNC Routers,Pick and Place and Milling Machine, lathe and cutters are just a few examples
- Main Features: 7 inch full color display screen; resolution ratio: 1024x600, 40 operation keys; 24 photoelectric isolated digital inputs, 21 photoelectric isolated digital outputs;Analog spindle control 0-10V spindle control, also support PWM Output;Compatible with standard G-code,support popular CAD/CAM software, such as ArtCam, MasterCam, ProE, JDSoft SurfMill, Aspire, Fusion 360 and so on
- More Features: Magazine type: Supports multiple spindle mode, support straight Tool Magazine, gantry type Magazine, disk type magazine; Probe Mode: Supprt Floating Probe and Fixed Probe; Backlash compensation methods: direction gap compensation, radius gap compensation, length compensation;The control system can preview the processing path before machining, and it makes the system more steady, working smoothy and precise etc.
- 24V DC Power Supply Input: DDCS-Expert needs two power supplies,Main power is for controller system,IO Port power is for Input and Output and MPG ports. Both power supply is 24VDC,current is 3A. In the System Power input port ,the marked 24V and GND is the main power input ports
- Powerful function: It can support mm and inch.The default is mm. If you need to set inch as the unit, please set it to imperial units through G20 code; Support un-limited size file for machining;Support Pause Breakpoint resume, Power Cut recovery, Start from the specific line; Support time-lock function;Support 4 kinds operation rights: visitor, operator, admin,super admin; Support function of Try cutting handwheel guiding and Single-stage processing mode and so on
Brand: CNCTOPBAOS
Voltage: 24 Volts
Material: Copper
Item Weight: 1.58 Kilograms
Display Type: LCD
Manufacturer: Changzhou Rattm Motor Co.,Ltd
Package Dimensions: 12.24 x 8.54 x 4.17 inches
Item Weight: 3.48 pounds
Is Discontinued By Manufacturer: No
Batteries required: No
Frequently asked questions
This product is currently out of stock. Please check back later for shipping info.
Yes, absolutely! You may return this product for a full refund within 30 days of receiving it.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
- Klarna Financing
- Affirm Pay in 4
- Affirm Financing
- Afterpay Financing
- PayTomorrow Financing
- Financing through Apple Pay
Learn more about financing & leasing here.
Similar Products
Top Amazon Reviews
Style: 5 Axis DDCS EXPERT Controller+MPG
Had a few issues but they respond well and overnight when you ask them a question. Be aware that this unit requires you to hook up both positive and negative terminals for all wires instead of having a common cathode or anode. A bit of a pain but I made it work. Has some nice software compared to my previous model.
...
show more
Reviewed in the United States on December 5, 2023 by Thomas E. Heinzen
Style: 5 Axis DDCS EXPERT Controller+MPG
Nice controller. Still working on getting everything dialed in. It didn’t come with much instruction, but the manual is available (2 parts) online. I got this during a Prime day, so the price was pretty good at that time. Watch for sales. I’m using it for a plasma cutter, but I’ve built it so I can use it with various equipment. (We shall see how that plays out?) Best of luck to you! I’ll take and post some shots and vids to follow up with this.
...
show more
Reviewed in the United States on February 8, 2025 by Dave Perry
Style: 4 Axis DDCS EXPERT Controller
This controller is a great value. This is a great choice for someone building their own CNC. Documentation is available from the manufacturers website. Most of the important stuff to look at is in the install folder. Slib-g and slib-m have all the macros. Eng file has a full list of all parameters. The comments are in Chinese, but they can be translated. It is possible to write user macros. There are some functions that do not work(G41,G42,G43). So far I am very impressed. Be sure to update it as well, there have been several updates since I got mine
...
show more
Reviewed in the United States on April 1, 2022 by Robert W. Hinman
Style: 4 Axis DDCS EXPERT Controller+MPG
Works great. Fairly easy to setup and install.
Reviewed in the United States on April 27, 2023 by Randy Welch
Style: 4 Axis DDCS EXPERT Controller+MPG
Great CNC. The company is quick with technical support.
Reviewed in the United States on May 26, 2022 by Thomas P.
Style: 4 Axis DDCS EXPERT Controller+MPG
Podría tener un manual mas completo, con ejemplos
Reviewed in the United States on August 8, 2024 by Carlos Rojas
Style: 4 Axis DDCS EXPERT Controller
The controller was well built, the UI is nice, but as of 10/2/2021 the unit does NOT support slaving an axis (X, Y, Z) to the 4th axis to allow for a dual motor driven axis. If your unit uses a single motor per axis on each of X, Y, and Z then you will be good to go, but if your machine is one of the larger machines that requires dual motors on any axis ( commonly X or Y ) then this unit will not work.
...
show more
Reviewed in the United States on October 2, 2021 by Billy Clay Myers
