CNCTOPBAOS CNC 3018-PRO-MAX 3 Axis Desktop DIY Mini Wood Router Kit PCB PVC Milling Engraver Engraving Carving Machine GRBL Control with offline controller Hand Control (w/Offline Controller)
Condition: New
Buy Now, Pay Later
As low as
$24.67
/ mo
Learn more
- – 6-month term
- – No impact on credit
- – Instant approval decision
- – Secure and straightforward checkout
Ready to go? Add this product to your cart and select a plan during checkout.
Payment plans are offered through our trusted finance partners Klarna, Affirm, Afterpay, Apple Pay, and PayTomorrow. No-credit-needed leasing options through Acima may also be available at checkout.
Learn more about financing & leasing here.
Selected Option
Free shipping on this product
30-day returns
Learn more
FREE 30-day refund/replacement
To qualify for a full refund, items must be returned in their original, unused condition. If an item is returned in a used, damaged, or materially different state, you may be granted a partial refund.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
Availability:
20 left in stock
Arrives
Sunday, Dec 21
Recently Viewed
Style: 3018-PRO-MAX w/ offline controller
Features
- Upgrade Version CNC3018-PRO-MAX with offline controller: Mini CNC machine small size, light weight, USB interface, GRBL control systems, great cnc router machine for beginners; You can operate this machine without connect the computer; Offline controller included a SD card reader to write into the root directory G-code files or NC file; Support manually adjust X, Y, Z axis location as engraving starting point,manually open or close spindle
- Working area: 30x18x4.5cm / 11.8 x 7.1 x 1.8 inches;Frame size: 42x35x27cm / 16.53 x 13.78 x 10.63 inches;Type:USB port Desktop cnc router; System requirements: Windows XP / Win 7 / Win 8 / Win 10 / Linux; Supporting files:G-code .nc/.txt/.tape/.gcode
- Spindle Motor: 775 120W spindle motor DC12-36V, 24V is 10000r/min; Collet: with ER11 3.175mm collet,also can be equipped with 0-7mm size; Stepper Motor: Nema17 42 stepper motor 1.33A/0.3N.m/43oz-in/42x42x34 mm
- Application: Can be engraved plastic, wood, acrylic, pvc, pcb, wood and the like material.soft metal like copper and aluminum and other materials; If you have the engraver module,you also can change the spindle to a 3-pin PWM engraver module,then also can engrave on kraft paper, wood, leather etc
Brand: CNCTOPBAOS
Material: Aluminum
Power Source: ac/dc
Product Dimensions: 7.09"W x 11.81"H
Voltage: 24 Volts
Brand: CNCTOPBAOS
Material: Aluminum
Power Source: ac/dc
Product Dimensions: 7.09"W x 11.81"H
Voltage: 24 Volts
Maximum Rotational Speed: 10000 RPM
Amperage: 5.6 Amps
Base Type: Fixed
Battery Description: Corded electric
UPC: 619191628254
Manufacturer: Changzhou Rattm Motor Co.,Ltd
Part Number: 3018
Item Weight: 15.71 pounds
Item model number: 3018
Is Discontinued By Manufacturer: No
Style: 3018-PRO-MAX w/ offline controller
Item Package Quantity: 1
Batteries Included?: No
Batteries Required?: No
Description Pile: Corded electric
Date First Available: May 1, 2020
Frequently asked questions
If you place your order now, the estimated arrival date for this product is:
Sunday, Dec 21
Yes, absolutely! You may return this product for a full refund within 30 days of receiving it.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
- Klarna Financing
- Affirm Pay in 4
- Affirm Financing
- Afterpay Financing
- PayTomorrow Financing
- Financing through Apple Pay
Learn more about financing & leasing here.
Similar Products
Top Amazon Reviews
Style: 3018 Pro Max w/ offline controller
Keeping in mind the size and power limit the work you can do, this is a remarkably solid little unit. More for carving/engraving and some "Light" mill work & routing. I found the assembly easy and had it running within a couple of hours. The software is crap (but I knew that going in) but there is plenty of good, free software out there that make getting started straight forward. More advanced Mill/routing work will have a steeper learning curve but that's in the CAD/CAM software, not the unit. The unit I got didn't come with a Z probe or limit switches (I knew that when I ordered) but the driver board is set up to accept them. I recommend adding the, I did. The newer Woodpecker 3.4 control board is not set up to receive an E-stop switch which it should (the older Cronos Maker board was so equiped). I'll wire mine into the DC Power line. A fair amount of upgrades are available but the base unit, as delivered, is solid. Plenty of You Tube tutorials for this unit are out there, Which I found to be of great help. All in all, Very satisfied.
...
show more
Reviewed in the United States on November 20, 2020 by Troy Stanton
Style: 3018 Pro Max
I bought this machine for the sole purpose of cutting a particular shape out of anodized 1/32 thick aluminum sheets. When the machine arrived, one of the stepper motors was defective and did not have enough torque to move the lead screw. After contacting support, they were able to assist and I was up and running! If you are cutting metals, the v bits that come with the machine are not going to get you very far. After some research, I got some up cut endmills that cut the aluminum, but broke very quickly. After more research into feeds and speeds and adding some oil to the surface of the aluminum, I am getting successful cuts without breaking bits! A few things to help get started with the machine! You are probably going to break a lot of bits starting out, so be prepared to budget for this and maybe start with some cheaper endmills before dropping a lot of money on the high end stuff. You will need a spoil board under your project if you are cutting all the way through. You can 3d print something to work if you have access to a 3d printer, or you can use wood. Of using wood, make sure it is flat, or mill it flat after installing. Go slow. The spindle in this machine is mounted with an injection molded plastic part that has a single screw to tighten the spindle into it. This piece will flex with enough resistance and ruin your project if your feeds and speeds are not right. Be patient. This machine is not an industrial machine at all, but rather an intro into the world of CNC milling. There are going to be ways to upgrade it with a better spindle, an offline controller, etc, but try using the machine as is before dumping extra money into upgrades that may not net the results you need.
...
show more
Reviewed in the United States on August 20, 2023 by Russel Samad
Style: 3018 Pro Max w/ offline controller
This is my initial review covering the packaging and installation. If you are thinking of purchasing this make sure you go to You tube and look up James Dean Designs. He has a whole series of videos covering the 3018 cnc routers and they are excellent. I ignored the documentation that came with it and used his installation video and it was easy. Couple of caveats on this model. I ordered it because it included sides. There is no documentation for them and the only bolts the were left over are really a little long. I went to Lowe's and replaced them. Also, I haven't done more than test the motion because the "set" of bits that came with it turned out to be all the same "v" bit, which wasn't what I needed for my first project. So order a set of bits along with the device. But all in all I am satisfied so far and will update this once I have done a few projects.
...
show more
Reviewed in the United States on August 5, 2023 by JimT
Style: 3018 Pro Max
El producto llegó en buenas condiciones, completo. Falta más explicación para el ensamble.
Reviewed in the United States on July 30, 2024 by Diana Agudelo
Style: 3018 Pro Max
Es muy fácil de armar siguiendo las instrucciones
Reviewed in the United States on July 27, 2024 by Henry
Style: 3018 Pro Max
Machine arrived undamaged. Came with a paper Part A: Assembly Instructions and Part B: User Manual, and remaining manuals, pictures and videos, controlling software, etc. on a thumbdrive. However, all the files on the thumbdrive were corrupted/un-usable. The was NO contact information to reach the Seller initially, but Amazon support directed me to a link to send the Seller a message. Still, the link says to wait several days for a response from the Seller. Not happy with the situation. Machine is un-useable as is - great paperweight at the moment.
...
show more
Reviewed in the United States on January 4, 2021 by Terry Monroe
Style: 3018 Pro Max
No matter what I do, I can't get the Y-axis table to move without binding. I've adjusted the sliders, slide rods and drive screw repeatedly. I tried lubing the drive screw and rods. The table is square to the frame and I tried swapping out the motor with the X-axis motor but get the same results. This is not the first time I've assembled something like this and I build stuff for a living so it's not lack of skill causing the issue. I have no idea how well the machine works because I haven't gotten that far yet. The X-axis and Z-axis components move fine and the spindle fires up on command so if I can get the Y-axis problem resolved, it should work fine. Amazon suggests I return the one I have for a replacement but then I'd have to disassemble the whole thing and pack it back up. I'd rather get help figuring out how to make it work or get replacement parts but I can't find any tech support contact information. Based on other reviews, this seems like an uncommon issue but it is still an issue.
...
show more
Reviewed in the United States on November 14, 2023 by John M.
Style: 3018 Pro Max w/ offline controller
buen producto.. probado... recomendado
Reviewed in the United States on June 24, 2024 by joel e.
