BIGTREETECH TMC2209 V1.3 Stepper Motor Driver, UART/Step/DIR Mode | Ultra Silent Stepstick Drivers with Heatsink for Octopus V1.1/Pro, SKR V1.4 Turbo/3, Manta M8P/M4P/M5P & MKS Gen L, 5Pcs
Buy Now, Pay Later
- – 4-month term
- – No impact on credit to apply
- – Instant approval decision
- – Secure and straightforward checkout
Ready to go? Add this product to your cart and select a plan during checkout.
Payment plans are offered through our trusted finance partners Klarna, Affirm, Afterpay, Zip, Apple Pay, and Google Pay. No-credit-needed leasing options through Acima may also be available at checkout.
Learn more about financing & leasing here.
Selected Option
FREE 30-day refund/replacement
To qualify for a full refund, items must be returned in their original, unused condition. If an item is returned in a used, damaged, or materially different state, you may be granted a partial refund.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
Style: 5*TMC2209
Features
- Ultra-silent Stepper Motor Driver: BIGTREETECH tmc2209 v1.3 stepper motor driver adopts StealthChop2 silent motor operation technology is an ultra-silent motor driver IC for two-phase stepper motors. Continuous current up to 2.0A (peak 2.8A), voltage ranges from 4.75v to the maximun output of 28v. It can operate bipolar stepper motors from 1 to 1/256 step modes
- BTT TMC2209 stepper motor driver support UART, STEP/ DIR Mode, except that you need to modify the firmware for the mode you use. for detailed tutorials, please refer to the BIGTREETECH GITHUB instructions
- Sensorless Homing: BTT tmc2209 v1.3 stepper motor driver uses Stallguard4 locked motor technology to detect changes in motor current, providing an abnormal signal when the motor rotates abnormally. And use this measurement to detect the end of axis' stroke and produce 3D printers without limit switches
- Widely Compatible: TMC 2209 stepper driver with most 3D printer motherboards on the market, such as btt octopus v1.1/octopus pro, skr v1.4 turbo/skr 3, Manta M4P/M5P/M8P, MKS Gen L... etc. It saves the expensive cost of redesign. It can perfectly replace the original non-silent TMC2100/A4988/DRV8825/LV8729 stepper driver and is the most cost-effective choice
- Avoid losing steps and jittering: The motor controlled by the PWM chopper mode operated more smoothly and without jitter. It can effectively avoid problemsuch as running deviation losing step and fault caused by the overlode of the chip. Better printing effect
Description
BIGTREETECH is commited to establishing a complete 3D printing ecosystem, striving to bring more possibilities to 3D printing industry and pushing the technological advancement of 3D printers to make 3D printers faster, better, and easier! BIGTREETECH TMC2209 V1.3 stepper motor driver adopts StealthChop2 ultra-quiet technology. It is an ultra-silent motor driver IC for two-phase stepper motors. Its continuous drive current is 2A and peak current is 2.8A. Compared with TMC2208, the driving current of this IC is not only improved by 0.6A-0.8A, but also this IC increases the function of locked-motor test. 1. When the driver is inserted into the motherboard, please pay attention to see the direction of the drive, can not be inserted in reverse, to prevent the drive from burning. 2. Be sure to do a good job before driving heat dissipation work (heat sink + fan), to prevent the drive is not working properly. 3. Pay attention to the wiring sequence and I/O port when wiring. If the wrong line is connected, the driver will not work properly. Please connect according to the Github manual. Control chip: TMC2209-LA Chip； Logic supply voltage(VIO): 3-5V； Motor supply voltage(VM): 4.75V-28V DC； Peak current: 2.8A； Current RMS: 2A； Native Microsteps 2: Up to 1/256； Operating mode: STEP/DIR or UART； Configuration: CFG Pins or UART； BIGTREETECH TMC2209 V1.3 stepper motor driver uses StealthChop2 ultra-quiet technology to reduce motor noise to a silent state, allowing it to operate in an extremely quiet environment. TMC2209 stepper driver uses SpreadCycle high-dynamic motor control chopper to control the motor to run more stably and without jitter, effectively avoiding problems such as deviation, step loss, and failure caused by chip overload. BTT TMC2209 V1.3 driver uses CoolStep current dynamic control to save 75% of energy. It has a large area heat dissipation pad to reduce the temperature of the driver during operation. BTT TMC2209 support STEP/DIR mode. Select working mode MS1, MS2, configure the micro-step resolution of stepper input. For detailed settings, please refer to TMC2209 V1.3 Github manual for settings. TMC2209 stepper motor driver defaults to UART mode. If you use the 5th pin as the UART pin, you need to remove the resistor and solder it to the two pads below. Turn the potentiometer clockwise: reduce Vref to reduce the driver current, turn it counterclockwise to increase the driver current.
Brand: BIGTREETECH
Model Name: tmc2209
Speed: 400 rpm
Voltage: 5.5 volts
Horsepower: 0.11 watts
Brand Name: BIGTREETECH
Model Name: tmc2209
Model: 5Pcs TMC2209 V1.3
Manufacturer: BIGTREETECH DIRECT
UPC: 787794452238
Global Trade Identification Number: 38
Part Number: 2019
Speed: 400 rpm
Voltage: 5.5 volts
Horsepower: 0.11 watts
Item Weight: 0.27 g
Material Type: PCB
