12" x 30" x 16" 3 Axis DRO Digital Readout for Mill DRO Magnetic Scale Encoder Milling Machine 320mm+770mm+420mm Tool IP67 Sealing Protection 9X42 Bridgeport Machine

Features

• High-Performance 3-Axis DRO System Designed for versatile application across milling machines (including Bridgeport types), lathes, and other workshop equipment. Features a bright 7-inch LCD screen that delivers clear, glare-reduced readings for effortless operation even under harsh lighting. The intuitive interface minimizes the learning curve, while the built-in digital user manual is always accessible on-screeneliminating the hassle of keeping track of paper documents and keeping your hands free to focus on the job at hand.
• Superior Quality & Reliable Components Powered by a 34-bit core processor with 64MB of onboard running memory, this DRO system delivers high integration and robust anti-interference performance for stable operation even in electrically noisy shop environments. The imported high-grade chips ensure faster data processing and real-time response, while the Mean Well power supply guarantees long-term reliability with extended service lifeminimizing downtime and maintenance concerns.
• The 3 Axis digital readout display meter system is equipped with a variety of intelligent functions:MM/INCH, SDM 200 sets memory, bevel processing, power-off memory, circumference drilling, oblique line drilling, 1/2 centering,Axis sunmming functuon etc. Extra RPM function,Also a calculator is equipped for more convenient usage
• What's in the Box: 1 3-Axis LCD Digital Readout Display 1 RPM Speed Sensor (Hall Effect type) 3 Magnetic Linear Scales (Lengths: 12 inch / 16 inch / 30 inch) 1 USA Standard Power Cord (AC plug) 1 Mounting Bracket Set (with hardware) 1 Screw Kit for installation 1 User Manual (printed copy)
• Easy Installation:Magnetic scales are impervious to coolant, liquid or dust, yet are slimmer than linear scale of the other two technologies. They're easier to mount, more durable, and can be broken down into convenient lengths for shipping.magnetic scales is that the readhead and the scale are completely separate components.This means mounting magnetic scales is easier than any other type scale - since the readhead mounts separately from the scale,mounting is much quicker,and a whole lot easier
• Magnetic Scale Interference-resistant, High-precision, and Durable. Utilizing a magnetic measurement principle, it is more resistant to oil, dust, chips, and vibration compared to traditional optical scales, making it especially suitable for harsh machining environments. It maintains stable and reliable measurement accuracy even after long-term use.

Description

eg 200mm travel length, total length =319mm Meanwell Power supply ,Omran Key button.Switch on& Switch off can meet more than 100000 times. The grating digital display body is made of high-quality Aluminum alloy which has high reliability and durability, corrosion resistance, and scratch resistance. We provide the spare fuse on the back of the digital display. Built in help function, freeing hands from paper manuals.Multi-language operation interface, easy to use. The digital readout display meter system is equipped with a variety of intelligent functions: SDM 200 sets memory, bevel processing, power-off memory, circumference drilling, oblique line drilling, 1/2 centering, also a calculator is equipped for more convenient usage. 1 :Special previewing the drawing function,after setting well the parameter,the Dro will display the machined well effect which makes the operating be ,ore visual 2 :Displaying the tool' s current position function,during the machining,the system will display the tool' s current position according to the drawing which makes the machining be much more easier. Vectoring function is used for displaying combined movement of either X – Z axis pair or Y– Z axes pair taking into consideration angle between Y and Z i.e. α. The resulting combined movement is displayed on X and Y axis.

Brand: Baykunl

Material: Paper

Product Dimensions: 12"L x 1.1"W

Range: 3.2E+2 Millimeters

Measurement Accuracy: Resolution 5um

Brand Name: Baykunl

Set Name: 3-axis DRO kit with 3 magnetic scales

Manufacturer: Chengdu Ditron measuring Co,.Ltd

Model: 12" x 30" x 16" 3 Axis DRO 5um

Part Number: D80M-3V RPM

Unit Count: 1.0 Count

Included Components: 3 Axis DRO Milling Machine

Range: 3.2E+2 Millimeters

Measurement Accuracy: Resolution 5um

Material Type: Paper

Item Dimensions L x W: 12"L x 1.1"W
