MATRIX LCR Meter, Capacitance Meter 40Hz-100kHz, Inductance Meter Accuracy 0.1%, Digital Multimeter with 32-Bit Core Processor, Electronic Component Tester 30Ω/100Ω Two Output Resistance, MCR-5100
Condition: New
Buy Now, Pay Later
As low as
/ mo
Learn more
- – Up to 36-month term if approved
- – No impact on credit to apply
- – Instant approval decision
- – Secure and straightforward checkout
Ready to go? Add this product to your cart and select a plan during checkout.
Payment plans are offered through our trusted finance partners Klarna, Affirm, Afterpay, Apple Pay, and PayTomorrow. No-credit-needed leasing options through Acima may also be available at checkout.
Learn more about financing & leasing here.
Selected Option
Free shipping on this product
30-day returns
Learn more
30-day refund/replacement
To qualify for a full refund, items must be returned in their original, unused condition. If an item is returned in a used, damaged, or materially different state, you may be granted a partial refund.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
Availability:
In Stock.
Arrives
May 10 – May 20
Recently Viewed
Style: 40Hz-100kHz
Features
- [PRECISION BENCH LCR METER] MATRIX high precision LCR meter MCR-5100 is a compact bench-type professional LCR meter with a 4.3-inch TFT LCD display. The LCR meter test frequency ranges from 40Hz to 100kHz, basic test accuracy is 0.1%, and a 5-digit test resolution impedance meter instrument meets the testing needs of various components and parameters.
- [EASY TO USE] The capacitance meter tester with the new 32-bit core processor, test parameters L, C, R, lZl, D, Q, X, ESR, (Deg), (Rad). 30,100 two different signal source output impedance. Benchtop inductance meter built-in comparator, 5-grade flexible qualified, and defective alarming mode shutdown automatically saves test conditions, and humanized operation.
- [PRODUCT FEATURE] MATRIX digital electronic component tester instrument internal more than 100 sets of settings files, U disk extension to save multiple groups of the test or recall simplified Chinese, English is optional. And the LCR meter supports the format FAT16, and FAT32 file systems.
- [38 TEST FREQUENCY POINTS] 40Hz, 50Hz, 60Hz, 75Hz, 100Hz, 120Hz, 150Hz, 200Hz, 250Hz, 300Hz, 400Hz, 500Hz, 600Hz, 750Hz, 800Hz, 1kHz, 1.5kHz, 2kHz, 2.5kHz, 3kHz, 4kHz, 5kHz, 6kHz, 7.5kHz, 10kHz, 12kHz, 15kHz, 15.7kHz, 16.2kHz, 20kHz, 25kHz, 30kHz, 40kHz, 50kHz, 60kHz, 66.6kHz, 75kHz, 100KhZ in total of 38 frequency points.
- [QUALITY CHECK] Buy precision LCR bridge meter, you will get 1* Benchtop LCR Meter, 1* Power Cord, 1* Four-terminal Test Cord, 1* CD, 1* Test Report, 1* User Manual, 1 * Fuse table. The LCR meter digital can be used for test passive components, such as incoming inspection, and the production and sorting of passive components.
Brand: MATRIX
Power Source: Corded Electric
Style: 40Hz-100kHz
Color: White
Item Weight: 10.58 Pounds
Power Source: Corded Electric
Minimum Operating Voltage: 99 Volts (DC)
Measurement Type: LCR Meter
Maximum Operating Voltage: 242 Volts (DC)
Style Name: 40Hz-100kHz
Color: White
Item Weight: 10.58 Pounds
Item Dimensions: 13 x 16 x 8 inches
Brand Name: MATRIX
Model: MCR-5100
Manufacturer: MATRIX TECHNOLOGY INC.
Included Components: 1
Warranty Description: 3 Year Manufacturer
Specification Met: CE
Frequently asked questions
If you place your order now, the estimated arrival date for this product is:
May 10 – May 20
Yes, absolutely! You may return this product for a full refund within 30 days of receiving it.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
- Klarna Financing
- Affirm Pay in 4
- Affirm Financing
- Afterpay Financing
- PayTomorrow Financing
- Financing through Apple Pay
Learn more about financing & leasing here.
Similar Products
Top Amazon Reviews
Style: 40Hz-200kHz
This is a great LCR meter once you take the time to understand the setup menu structure. Definitely turn on averaging to get stable readings. Zip tie the test leads together as far as possible toward the clips if you are measuring small value inductors. Buy a standard component test fixture and shorting bar if you are measuring leaded parts.
...
show more
Reviewed in the United States on January 2, 2026 by William E Coleman
Style: 40Hz-200kHz
I needed to upgrade my LC measurement and found this meter through reviews and articles. This instrument is feature rich and an excellent bench LC measurement system. I have checked this with several capacitance and inductance standards and it is well within the stated specifications and as indicated on the included calibration sheet that came with the instrument. It is high quality and definitely at the upper end of the general bench LC measurement systems.
...
show more
Reviewed in the United States on July 29, 2025 by Dan72
Style: 40Hz-200kHz
Whether you want to find Mike Row Henry or just bust a cap, this meter does it all. Easy calibration, nice ref settings and ridiculously accurate. I mostly use this for capacitors and hand wound transformers and it never disappoints. The quality, look and feel of this unit is far superior to others I have used with the same form factor. Highly recommend and well worth the price.
...
show more
Reviewed in the United States on March 31, 2026 by UNI
Style: 100Hz-10kHz
I bought this unit mainly to test capacitors out of circuit which seems simple enough but the readings I get are completely out of range so I reached out to Matrix for help, they wanted to know about what frequency range, resistance, etc. I need. I attempted on several occasions to contact them but first their webpage didn't work then their mailbox was full and now I can't seem to contact them through Amazon. Maybe I got a bad unit, probably I don't know what I am doing and how to operate the tester but the lack of technical support (in China) is practically non-existent. I would not recommend this product, I will stick to my old tried and true Sencore LC-103.
...
show more
Reviewed in the United States on March 13, 2021 by Arkie
Style: 40Hz-200kHz
Hello! First I would like to say that I originally ordered the MCR-5100 and received the MCR-5030 by mistake so the beginning of this experience was a little rocky. All of the order info was correct, and I confirmed that I did not order the wrong one by mistake. Then, I ordered a replacement thinking that the actual item would arrive since the technical info stated on the order was the MCR-5100. What are the odds, I received the wrong one again? When I contacted Amazon they pointed me to the Seller. After a quick exchange with the Seller it was determined that it was, in fact, an Amazon stocking issue since it was shipped directly from an Amazon facility and it will take some time to straighten that out. So here is where everything goes great.... The Seller Matrix Technology quickly remedied the situation by giving me a significantly reduced price on the MRC-5200 (pretty close to the cost of the MCR-5100) which exceeded my original frequency requirements. Today I received it in the mail and did some quick measurements on my reference inductors & Resistor with all measurements well within the advertised specification tolerances. So.. I am very happy with the product and recommend it for the price as well as their customer service. My only gripe now is trying to find the RS232 and/or GPIB command set for remote communications. There was no information in the box. Hopefully customer service continues to impress... Have a great day!
...
show more
Reviewed in the United States on November 30, 2021 by Conrad A. Ihla
Style: 40Hz-200kHz
You don't need to shell out $3K or more for a Keysight (Agilent) LCR meter. This Matrix MCR-5200 LCR meter is a fine replacement and is actually better in many ways. The LCR ranges are more than adequate for most electronics work. I do a lot of audio and RF work and rely on mine to tell me the true value of components pretty much every day. The accuracy is outstanding. Can't be beat for the money.
...
show more
Reviewed in the United States on July 25, 2024 by David Fifield
Style: 40Hz-200kHz
I use this product to help design RF filters, where I need to measure capacitor values below one picofarad and my inductors are 100 nanohenries. IOW, very tiny components!! This product is doing a good job of measuring them. I needed product support in order to get a test fixture; they answered every question promptly. I would give them 5 stars if the English in the product manual and on the LCD screen was perfect. It isn't, but this is still appears to be the best value in a professional LCR. 4 stars and a strong endorsement from me.
...
show more
Reviewed in the United States on June 8, 2022 by Amazon Customer
Style: 40Hz-100kHz
This Lcr meter has been great so far. It’s been about 6 months. It makes troubleshooting and repairs so much easier and faster. Now I don’t have to remove the caps to get an accurate reading. It’s so nice being able to test in circuit. Absolutely a must for car and home audio amplifier repairs. Great product. Will update if any issues arise.
...
show more
Reviewed in the United States on October 26, 2023 by jeremy l.
