CNC Router Machine 4030-Evo Ultra 2, All-Metal XYZ Axis Dual Steel Linear Guides & Ball Screws with 800W Trim Router for Metal Aluminum Brass Wood Acrylic PCB
Condition: New
Checking for product changes
Buy Now, Pay Later
As low as
/ mo
Learn more
- – Up to 36-month term if approved
- – No impact on credit
- – Instant approval decision
- – Secure and straightforward checkout
Ready to go? Add this product to your cart and select a plan during checkout.
Payment plans are offered through our trusted finance partners Klarna, PayTomorrow, Affirm, Afterpay, Apple Pay, and PayPal. No-credit-needed leasing options through Acima may also be available at checkout.
Learn more about financing & leasing here.
Free shipping on this product
30-day returns
Learn more
30-day refund/replacement
To qualify for a full refund, items must be returned in their original, unused condition. If an item is returned in a used, damaged, or materially different state, you may be granted a partial refund.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
Availability:
Only 3 left in stock, order soon!
Arrives
Friday, Jun 20
Recently Viewed
Features
- [Upgraded 65mm Trim Router] 800W trim router & Er11-1/8" collet with 6-speed settings (8000-24000 RPM). Software-controlled run/stop functionality, with speed adjustment requiring manual dial control.
- [Dual Linear Rails and Ball Screws] Each axis (X, Y, Z) equipped with HGH-15 dual linear rails and 1204 ball screws. Enhances precision, rigidity, and load capacity for metal cutting, with improved dust protection for the X&Y axes.
- [Grbl_ESP32 Firmware (GRBL 1.3a)] Optimized control board, runs on the latest GRBL 1.3a firmware, supporting advanced features such as laser engraving, 4th axis (rotary axis), M07/M08 coolant control, closed-loop stepper motors, and a 3-pin touch probe.
- [Nema 23 Stepper Motors] XYZ axes feature Nema 23 stepper motors (2.8A, 1.2N/m torque), with closed-loop interfaces for easy upgrades, easy replacement, plug and play.
- [Customizable Macro Buttons & WiFi] Built-in 32-bit MCU with ESP3D Web UI, enabling control via PC, smartphone, or tablet without USB cable. Macro button defaul is homing, reprogrammable for tasks like pause/stop/reset or executing G-code from an SD card.
- [Software & Fully Functional] Compatible with Windows, Linux, and Mac, supporting GRBL-compatible software such as UGS, Fusion360, VCarve, Easel, and Lightburn etc..Includes XYZ dual limit switches, home switch, emergency stop switch, Z probe tool.
- [Easy Assembly and User Support] Major components pre-assembled with clear cable management, accompanied by a detailed paper user manual and assembly/demo video for quick setup.
Description
Work Area: 400x300x130mm Overall Dimensions(LxWxH): 680x630x520mm Firmware: Grbl 1.3a Driver: TB67S109AFTG Max Speed: 3000mm/min Spindle: 800w Φ65mm Trim Router, 8000-24000RPM Stepper: Nema 23 Table Aluminum Plate Height Error: 0.1-0.5mm
Brand: AnoleX
Material: Aluminum
Power Source: Corded Electric
Product Dimensions: 24.8"W x 20.47"H
Voltage: 110 Volts
Brand: AnoleX
Material: Aluminum
Power Source: Corded Electric
Product Dimensions: 24.8"W x 20.47"H
Voltage: 110 Volts
Item Weight: 38 Kilograms
Maximum Rotational Speed: 24000 RPM
Base Type: Fixed
Manufacturer: AnoleX
Part Number: 4030-Evo_Ultra2
Item Weight: 83.6 pounds
Country of Origin: China
Item model number: 4030-Evo Ultra2
Size: 400*300
Color: Black
Style: Ultra2
Wattage: 800 watts
Item Package Quantity: 1
Included Components: CNC Router Kit
Batteries Included?: No
Batteries Required?: No
Date First Available: January 13, 2025
Frequently asked questions
If you place your order now, the estimated arrival date for this product is:
Friday, Jun 20
Yes, absolutely! You may return this product for a full refund within 30 days of receiving it.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
To initiate a return, please visit our Returns Center.
View our full returns policy here.
- Klarna Financing
- Affirm Pay in 4
- Affirm Financing
- Afterpay Financing
- PayTomorrow Financing
- Financing through Apple Pay
Learn more about financing & leasing here.
Similar Products
Top Amazon Reviews
The good Very stiff, relatively large capacity, strong sturdy construction. Knobs on XYZ allow you to easily manually index when the machine is off. Generous Z axis travel and you can configure how high off the bed it is via the rail set screws on the back, which also helps get the Z Gantry to clear the work. great support. Available options via the 1.5kw VFD spindle and Closed Loop steppers allow you to build as need grow. The bad 500w motor is fine for 1/8 cutters, but I did not find it powerful enough or productive enough for larger work. It also didnt have the stiffness needed for harder metals. There are certainly a lot of CNC routers will smaller motors being sold, so this isnt a low power option in general, but either the makita router or 1.5KW anolex spindle upgrade delivers the kind of power for tougher projects. My first one was a dud, and had to contact support - who were very responsive and helpful and got it sorted out. Dont expect any guidance on speeds and feeds and depth of cut from anolex, if it exists, i didnt find it. The other if you are cutting metals, you may find the lower Z limit switch cutout acts like a funnel bringing in metal chips down to the switch circuit board, and eventually causing an alarm code from the z limit. I found that some tape over the gap where the z limit switch sits in the cutout resolved this.
...
show more
Reviewed in the United States on February 23, 2025 by matthew
I bought one of these for my home shop and I'm very happy with it. While it's not commercial grade, it stands head and shoulders above the the belt and pully style machines that have defined hobby CNC over the last ten years or so. I can push 1/4" endmills to their limit in wood and still have room to spare as far as machine rigidity is concerned. For example, when using adaptive clear on a deep chunk of wood I'll set my stepdown to the full length of the flute (1"/25mm) and my stepover to 1.25mm (20% diameter of the tool) and just let 'er rip. Additionally customer support is fantastic, the stock motor controller burned out and Arlan from the tech support team sent me a new one free of charge. Additionally he's always available to answer questions. I can't tell you how much of a game changer this personal touch is in building consumer confidence for international brands where culture/language barriers can be dicey. My one piece of advice for people buying this machine is this, a "real" spindle is a MUST. The 500w that comes with this thing is comically underpowered for what the stock machine is otherwise capable of. Get a 65mm ER16 spindle from G-Penny or some other brand to unlock the potential of your machine, upgrading steppers is also a good idea from a speed/acceleration is concerned but not critical. TLDR, I strongly recommend for a desktop sized powerhouse. Well done Anolex!
...
show more
Reviewed in the United States on November 21, 2024 by Northorn Northorn
Style: Ultra2
The media could not be loaded. Very high quality machine! Easy to assemble and set up! Very impressive & highly accurate piece of equipment. Able to machine a complex aircraft instrument panel in the first week of operation. Excellent customer service! 5 STARS ALL THE WAY!
Reviewed in the United States on March 26, 2025 by Amazon Customer Amazon Customer
I wont be able to use for a few weeks I had emergency surgery so I cant assemble it just yet but i can see it is one very well made very well designed kits. I went ahead and ordered the closed loop stepper motors for it. Anolex 4303 evo Ultra is a very well constructed and going to be very Rigid Cant wait to get it set up and running I have lots of plans for this "ATM machine" I will be making die parts from A-2 Pre heat treated.
...
show more
Reviewed in the United States on November 13, 2024 by David casto
The media could not be loaded. I would recommend this machine if you are looking for something compact that can handle aluminum well. The Frame is very well built, no noticible deflection compared to most of the other smaller machines that looks like this. The upgrades rails, ballscrews and larger steppers all work well. It comes with a nice, full color manual in decent english, and they have been responsive to questions to their support email. The stock spindle seems to work okay, even on aluminum, though I also bought the 65mm adapter and upgraded to a palm router for more power. Cable/wire management also is pretty good out of the box. I also like having wireless control built in, it allows me to jog the machine and zero my coordinates using the web browser on my phone. You can tell Anolex is actually trying to build a good product and this is not just a cheap clone. I think the only knocks on it is that it should have come with the MDF spoilboard for the price and it would have been nice if they included some endmills other than the small v-carve bits out of the box. I have added a small low profile vice, the spillboard and am slowing working up a small enclosre as it DOES throw shavings everywhere. :)
...
show more
Reviewed in the United States on April 26, 2024 by Lauren B Lauren B
Style: Ultra2
Great machine!
Reviewed in the United States on April 23, 2025 by sean purdy
